Schall-Ex®
The synonym for automatic door seals.
The Schall-Ex® is the classic automatic seal. Thanks to the tool-free adjustable sliding release, time is saved during assembly.
Characteristics
- Seal for Pivot Doors - L15/30 WS Length 1458 mm
- Suitable for single-acting pivot doors
- Top and bottom sealing
- Includes magnetic sealing profile
Use
- sound protection
- Smoke protection
- Fire protection
- Accessibility
Application area
- Inside Door
- Exterior Door
Function
- Hinged Door
- Swing Door
Door Material
- Wood
Technical data
Broad | 15mm |
Height | 30mm |
Min. Delivery Length | 235mm |
Max. Delivery Length | 2000mm |
Default Length | 833mm 958mm 1083mm 1208mm |
travel | 20mm |
performance | Single-sided |
Actuator | Roll actuator |
Exterior Profile | Aluminum |
Surface |
Plate finish |
Material sealing profile | Silicone, self-extinguishing |
Additional Information
- It can be cut up to a maximum of 90 mm.
